SEALEVEL | SeaIO

SeaI/O-410S-OEM

Now includes NABL Calibration Certificate.
Rs. 28956.00

SeaI/O-410S-OEM is a compact RS-232 Modbus RTU interface module that provides 16 optically isolated inputs and 16 Reed relay outputs, perfect for low-current control and monitoring applications..

Quantity:
- +
Product added to cart successfully
  • Detail
  • Special Features
  • Specification

The SeaI/O-410S-OEM is a versatile Modbus RTU I/O interface offering 16 optically isolated digital inputs and 16 Reed relay outputs, ideal for controlling low-current devices such as alarms, solenoids, and lights. Its inputs support a wide voltage range of 5–30VDC, with optical isolation to protect sensitive equipment from noise and electrical transients.

The Reed relays (Form A) provide long-life switch closures and can handle low-power AC or DC loads. The module is powered by a 9–30VDC source and communicates using the industry-standard Modbus RTU protocol over RS-232. It integrates easily with Sealevel's SeaMAX software drivers, enabling smooth integration with Microsoft Windows and Linux systems.

The SeaI/O-410S-OEM’s modular design allows for system expansion, supporting up to 246 SeaI/O N-series modules, making it a flexible choice for large-scale control and monitoring systems.

  • 16 optically isolated inputs (5–30VDC)

  • 16 Reed relays (Form A) for long-life switching

  • RS-232 Modbus RTU communication interface

  • Grouped input/output configuration for simplified wiring

  • Powered by 9–30VDC

  • Supports Sealevel SeaMAX API for Windows & Linux

  • Expands with up to 246 SeaI/O N-series modules

  • Board-only form factor for embedded applications

  • Host Interface: RS-232 (Modbus RTU)

  • Digital Inputs: 16 optically isolated (5–30VDC)

  • Relay Outputs: 16 Reed relays (Form A)

  • Power Requirement: 9–30 VDC @ 1.6W

  • Operating Temperature: 0°C to 70°C (32°F to 158°F)

  • Storage Temperature: -50°C to 105°C (-58°F to 221°F)

  • Dimensions: 7.5" (L) x 5.0" (W) x 0.8" (H)

  • Humidity Range: 10–90% RH (non-condensing)

  • Software Support: SeaMAX API for Windows & Linux

  • Expansion: Supports up to 246 SeaI/O N-series modules

  • Form Factor: Board only
